N9020A MXA Signal Analyzer, 10 Hz to 26.5 GHz

Lượt xem : 768

Key Features and Functions



Accelerate the development of wireless devices with the speed, performance & applications to adapt to evolving test requirements

Shorten test times with rapid local measurements, display updates, marker peak searches & fast sweep

Simplify testing with fast one-button measurements from X-Series apps: LTE, WLAN, MSR & more

Capture elusive or transient signals with full-band real-time spectrum analysis

Perform deeper troubleshooting with the 89600 VSA software



Signal Analyzer N9020A 012



Specification



Frequency 10 Hz to 26.5 GHz

Frequency Options 3.6, 8.4, 13.6, 26.5 GHz, Mixers to 1.1 THz

Standard Attenuator Range 70 dB

Standard Attenuator Step 2 dB

Real-Time Bandwidth Options 85, 125, 160 MHz

DANL @1 GHz -172 dBm

Maximum Analysis Bandwidth 160 MHz

Phase Noise @1 GHz (1 MHz offset) -136 dBc/Hz

Phase Noise @1 GHz (10 kHz offset) -114 dBc/Hz

Phase Noise @1 GHz (30 kHz offset) -114 dBc/Hz

Spur Free Dynamic Range 72 dBc

TOI @1 GHz (3rd Order Intercept) +20 dBm

Applications Available Yes

Maximum Real-Time Bandwidth 160 MHz

Overall Amplitude Accuracy ±0.23 dB

Bandwidth Options 25 standard, 40, 85, 125, 160 MHz

Performance Level ◆◆◆◆◇◇

Applications-Cellular

1xEV-DO

cdma2000

cdmaOne

GSM/EDGE/EDGE Evolution

iDEN/WiDEN/MotoTalk

TD-SCDMA with HSDPA/HSUPA/8PSK

LTE/LTE-Advanced

W-CDMA/HSPA/HSPA+

Applications-Digital Video

Digital Cable TV

DTM B

ISDB-T/Tmm

DVB-T/H/T2/T2-Lite

Applications-General Purpose

89600 VSA Software

Analog Demodulation

EMI Precompliance

Flexible Digital Modulation Analysis

MATLAB

Noise Figure

Phase Noise

Pulse

Real-Time Spectrum Analysis

Remote Language Compatibility

SCPI Code Compatibility

Stimulus Response

Applications-Wireless Connectivity

802.16 OFDMA

WLAN (802.11a/b/g/p/j/n/ac/ah/ax)

Bluetooth® (BR/EDR/LE4.2/5.0)

Maximum Dynamic Range 3rd Order @1 GHz 116 dB

Minimum Duration for 100% Probability of Intercept 3.57 µs

Detectable Signal Duration w/Signal to Mask >60 dB 5 ns

Multi-Domain Bandwidth 160 MHz

Display Views

Density

Spectrogram

Density Spectrogram

PvT (Power vs. Time) Spectrum

PvT (Power vs. Time) Spectrogram

PvT (Power vs Time)

Triggering

FMT (Frequency Mask Trigger)

TQT (Time Qualified Trigger)

Level

RF Burst

Line

External

Periodic

Applications with Frequency Mask Trigger

89600 VSA Software

Real-Time Spectrum Analyzer

DANL @2 GHz, No Preamplifier -154 dBm/Hz

DANL @10 GHz, No Preamplifier -151 dBm/Hz

Benchtop Yes



Real-Time Data Streaming No



Source: Keysight
